Microsoft Windows* Records
System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel
®
Xeon
®
Processor E5 4600/2600/2400/1600/1400 Product Families
124 Intel order number G90620-002 Revision 1.1
14. Microsoft Windows* Records
With Microsoft Windows Server 2003* R2 and later versions, an Intelligent Platform Management Interface (IPMI) driver was added.
This added the capability of logging some OS events to the SEL. The driver can write multiple records to the SEL for the following
events:
 Boot-up
 Shutdown
 Bug Check / Blue Screen
14.1 Boot up Event Records
When the system boots into the Microsoft Windows* OS, two events can be logged. The first is a boot-up record and the second is
an OEM event. These are informational only records.
Table 98: Boot up Event Record Typical Characteristics
Byte
Field
Description
8
9
Generator ID
0041h – System Software with an ID = 20h
11
Sensor Type
1Fh = OS Boot
12
Sensor Number
00h
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 6Fh (Sensor Specific)
14
Event Data 1
[7:6] – 00b = Unspecified Event Data 2
[5:4] – 00b = Unspecified Event Data 3
[3:0] – Event Trigger Offset = 1h = C: boot completed
15
Event Data 2
Not used
16
Event Data 3
Not used
