Intel S1400FP - Table 104: Bug Check;Blue Screen Code OEM Event Record Typical Characteristics

System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel
®
Xeon
®
Processor E5 4600/2600/2400/1600/1400 Product Families
Microsoft Windows* Records
Revision 1.1 Intel order number G90620-002 129
Table 104: Bug Check/Blue Screen code OEM Event Record Typical Characteristics
Byte
Field
Description
1
2
Record ID
ID used for SEL Record access
3
Record Type
[7:0] – DEh = OEM timestamped, bytes 8-16 OEM defined
4
5
6
7
Timestamp
Time when the event was logged. LS byte first.
8
9
10
IPMI Manufacturer ID
0137h (311) = IANA enterprise number for Microsoft
0157h (343) = IANA enterprise number for Intel
The value logged depends on the Intelligent Management Bus Driver (IMBDRV) that is loaded.
11
Sequence Number
Sequential number reflecting the order in which the records are read. The numbers start at 1 for the first entry in the SEL
and continue sequentially to n, the number of entries in the SEL.
12
13
14
15
Bug Check / Blue Screen
Data
The first record of this type contains the Bug Check / Blue Screen Stop code and is followed by the four Bug Check / Blue
Screen parameters. LSB first.
Note that each of the Bug Check / Blue Screen parameters requires two records each.
Both of the two records for each parameter have the same Record ID.
There is a total of nine records.
16
Operating system type
00 = 32-bit OS
01 = 64-bit OS
