True Scale Fabric Switches 12000 Series Hardware
July 2015 Installation Guide
Order Number: G91928004US 35
12000 Series Switches
8. If applicable, install the optional cable management guides. Fasten to the EIA rails
with M6 screws. Torque all screws to 30in-lb.
Figure 27. U Bracket Installation
