Intel® Xeon™ Processor with 800 MHz System Bus
64 Datasheet
AA26 VCC Power/Other AC4 VCC Power/Other
AA27 D1# Source Sync I/O AC5 D60# Source Sync I/O
AA28 N/C N/C N/C AC6 D59# Source Sync I/O
AA29 N/C N/C N/C AC7 VSS Power/Other
AA30 VSS Power/Other AC8 D56# Source Sync I/O
AA31 VCC Power/Other AC9 D47# Source Sync I/O
AB1 VSS Power/Other AC10 VTT Power/Other
AB2 VCC Power/Other AC11 D43# Source Sync I/O
AB3 BSEL1 Power/Other Output AC12 D41# Source Sync I/O
AB4 VCCA Power/Other Input AC13 VSS Power/Other
AB5 VSS Power/Other AC14 D50# Source Sync I/O
AB6 D63# Source Sync I/O AC15 DP2# Common Clk I/O
AB7 PWRGOOD Async GTL+ Input AC16 VCC Power/Other
AB8 VCC Power/Other AC17 D34# Source Sync I/O
AB9 DBI3# Source Sync I/O AC18 DP0# Common Clk I/O
AB10 D55# Source Sync I/O AC19 VSS Power/Other
AB11 VSS Power/Other AC20 D25# Source Sync I/O
AB12 D51# Source Sync I/O AC21 D26# Source Sync I/O
AB13 D52# Source Sync I/O AC22 VCC Power/Other
AB14 VCC Power/Other AC23 D23# Source Sync I/O
AB15 D37# Source Sync I/O AC24 D20# Source Sync I/O
AB16 D32# Source Sync I/O AC25 VSS Power/Other
AB17 D31# Source Sync I/O AC26 D17# Source Sync I/O
AB18 VCC Power/Other AC27 DBI0# Source Sync I/O
AB19 D14# Source Sync I/O AC28 N/C N/C N/C
AB20 D12# Source Sync I/O AC29 N/C N/C N/C
AB21 VSS Power/Other AC30 SLEW_CTRL Power/Other Input
AB22 D13# Source Sync I/O AC31 VCC Power/Other
AB23 D9# Source Sync I/O AD1 VCCPLL Power/Other Input
AB24 VCC Power/Other AD2 VCC Power/Other
AB25 D8# Source Sync I/O AD3 VSS Power/Other
AB26 D7# Source Sync I/O AD4 VCCIOPLL Power/Other Input
AB27 VSS Power/Other AD5 TESTHI5 Power/Other Input
AB28 N/C N/C N/C AD6 VCC Power/Other
AB29 N/C N/C N/C AD7 D57# Source Sync I/O
AB30 VCC Power/Other AD8 D46# Source Sync I/O
AB31 VSS Power/Other AD9 VSS Power/Other
AC1 Reserved Reserved Reserved AD10 D45# Source Sync I/O
AC2 VSS Power/Other AD11 D40# Source Sync I/O
AC3 VCC Power/Other AD12 VTT Power/Other
Table 22. Pin Listing by Pin Number (Sheet 7 of 8)
Pin
No.
Pin Name
Signal
Buffer Type
Direction
Pin
No.
Pin Name
Signal
Buffer Type
Direction
