Intel® Xeon™ Processor with 800 MHz System Bus
50 Datasheet
5.1.1 Pin Listing by Pin Name
Table 21. Pin Listing by Pin Name (Sheet 1 of 8)
Pin Name
Pin
No.
Signal
Buffer Type
Direction Pin Name
Pin
No.
Signal
Buffer Type
Direction
A3# A22 Source Sync I/O AP1# D9 Common Clk I/O
A4# A20 Source Sync I/O BCLK0 Y4 Sys Bus Clk Input
A5# B18 Source Sync I/O BCLK1 W5 Sys Bus Clk Input
A6# C18 Source Sync I/O BINIT# F11 Common Clk I/O
A7# A19 Source Sync I/O BNR# F20 Common Clk I/O
A8# C17 Source Sync I/O BOOT_SELECT G7 Power/Other Input
A9# D17 Source Sync I/O BPM0# F6 Common Clk I/O
A10# A13 Source Sync I/O BPM1# F8 Common Clk I/O
A11# B16 Source Sync I/O BPM2# E7 Common Clk I/O
A12# B14 Source Sync I/O BPM3# F5 Common Clk I/O
A13# B13 Source Sync I/O BPM4# E8 Common Clk I/O
A14# A12 Source Sync I/O BPM5# E4 Common Clk I/O
A15# C15 Source Sync I/O BPRI# D23 Common Clk Input
A16# C14 Source Sync I/O BR0# D20 Common Clk I/O
A17# D16 Source Sync I/O BR1# F12 Common Clk Input
A18# D15 Source Sync I/O BR2#
1
E11 Common Clk Input
A19# F15 Source Sync I/O BR3#
1
D10 Common Clk Input
A20# A10 Source Sync I/O BSEL0 AA3 Power/Other Output
A21# B10 Source Sync I/O BSEL1 AB3 Power/Other Output
A22# B11 Source Sync I/O COMP0 AD16 Power/Other Input
A23# C12 Source Sync I/O COMP1 E16 Power/Other Input
A24# E14 Source Sync I/O D0# Y26 Source Sync I/O
A25# D13 Source Sync I/O D1# AA27 Source Sync I/O
A26# A9 Source Sync I/O D2# Y24 Source Sync I/O
A27# B8 Source Sync I/O D3# AA25 Source Sync I/O
A28# E13 Source Sync I/O D4# AD27 Source Sync I/O
A29# D12 Source Sync I/O D5# Y23 Source Sync I/O
A30# C11 Source Sync I/O D6# AA24 Source Sync I/O
A31# B7 Source Sync I/O D7# AB26 Source Sync I/O
A32# A6 Source Sync I/O D8# AB25 Source Sync I/O
A33# A7 Source Sync I/O D9# AB23 Source Sync I/O
A34# C9 Source Sync I/O D10# AA22 Source Sync I/O
A35# C8 Source Sync I/O D11# AA21 Source Sync I/O
A20M# F27 Async GTL+ Input D12# AB20 Source Sync I/O
ADS# D19 Common Clk I/O D13# AB22 Source Sync I/O
ADSTB0# F17 Source Sync I/O D14# AB19 Source Sync I/O
ADSTB1# F14 Source Sync I/O D15# AA19 Source Sync I/O
AP0# E10 Common Clk I/O D16# AE26 Source Sync I/O
