Intel® Xeon™ Processor with 800 MHz System Bus
Datasheet 51
D17# AC26 Source Sync I/O D57# AD7 Source Sync I/O
D18# AD25 Source Sync I/O D58# AE7 Source Sync I/O
D19# AE25 Source Sync I/O D59# AC6 Source Sync I/O
D20# AC24 Source Sync I/O D60# AC5 Source Sync I/O
D21# AD24 Source Sync I/O D61# AA8 Source Sync I/O
D22# AE23 Source Sync I/O D62# Y9 Source Sync I/O
D23# AC23 Source Sync I/O D63# AB6 Source Sync I/O
D24# AA18 Source Sync I/O DBSY# F18 Common Clk I/O
D25# AC20 Source Sync I/O DEFER# C23 Common Clk Input
D26# AC21 Source Sync I/O DBI0# AC27 Source Sync I/O
D27# AE22 Source Sync I/O DBI1# AD22 Source Sync I/O
D28# AE20 Source Sync I/O DBI2# AE12 Source Sync I/O
D29# AD21 Source Sync I/O DBI3# AB9 Source Sync I/O
D30# AD19 Source Sync I/O DP0# AC18 Common Clk I/O
D31# AB17 Source Sync I/O DP1# AE19 Common Clk I/O
D32# AB16 Source Sync I/O DP2# AC15 Common Clk I/O
D33# AA16 Source Sync I/O DP3# AE17 Common Clk I/O
D34# AC17 Source Sync I/O DRDY# E18 Common Clk I/O
D35# AE13 Source Sync I/O DSTBN0# Y21 Source Sync I/O
D36# AD18 Source Sync I/O DSTBN1# Y18 Source Sync I/O
D37# AB15 Source Sync I/O DSTBN2# Y15 Source Sync I/O
D38# AD13 Source Sync I/O DSTBN3# Y12 Source Sync I/O
D39# AD14 Source Sync I/O DSTBP0# Y20 Source Sync I/O
D40# AD11 Source Sync I/O DSTBP1# Y17 Source Sync I/O
D41# AC12 Source Sync I/O DSTBP2# Y14 Source Sync I/O
D42# AE10 Source Sync I/O DSTBP3# Y11 Source Sync I/O
D43# AC11 Source Sync I/O FERR#/PBE# E27 Async GTL+ Output
D44# AE9 Source Sync I/O FORCEPR# A15 Async GTL+ Input
D45# AD10 Source Sync I/O GTLREF W23 Power/Other Input
D46# AD8 Source Sync I/O GTLREF W9 Power/Other Input
D47# AC9 Source Sync I/O GTLREF F23 Power/Other Input
D48# AA13 Source Sync I/O GTLREF F9 Power/Other Input
D49# AA14 Source Sync I/O HIT# E22 Common Clk I/O
D50# AC14 Source Sync I/O HITM# A23 Common Clk I/O
D51# AB12 Source Sync I/O IERR# E5 Async GTL+ Output
D52# AB13 Source Sync I/O IGNNE# C26 Async GTL+ Input
D53# AA11 Source Sync I/O INIT# D6 Async GTL+ Input
D54# AA10 Source Sync I/O LINT0/INTR B24 Async GTL+ Input
D55# AB10 Source Sync I/O LINT1/NMI G23 Async GTL+ Input
D56# AC8 Source Sync I/O LOCK# A17 Common Clk I/O
Table 21. Pin Listing by Pin Name (Sheet 2 of 8)
Pin Name
Pin
No.
Signal
Buffer Type
Direction Pin Name
Pin
No.
Signal
Buffer Type
Direction
