Intel® Xeon™ Processor with 800 MHz System Bus
52 Datasheet
MCERR# D7 Common Clk I/O TCK E24 TAP Input
N/C Y29 N/C N/C TDI C24 TAP Input
N/C AA28 N/C N/C TDO E25 TAP Output
N/C AA29 N/C N/C TEST_BUS A16 Power/Other I/O
N/C AB28 N/C N/C TESTHI0 W6 Power/Other Input
N/C AB29 N/C N/C TESTHI1 W7 Power/Other Input
N/C AC28 N/C N/C TESTHI2 W8 Power/Other Input
N/C AC29 N/C N/C TESTHI3 Y6 Power/Other Input
N/C AD28 N/C N/C TESTHI4 AA7 Power/Other Input
N/C AD29 N/C N/C TESTHI5 AD5 Power/Other Input
N/C AE30 N/C N/C TESTHI6 AE5 Power/Other Input
ODTEN B5 Power/Other Input THERMDA Y27 Power/Other Output
OPTIMIZED/COMPAT# C1 Power/Other Input THERMDC Y28 Power/Other Output
PROCHOT# B25 Async GTL+ Output THERMTRIP# F26 Async GTL+ Output
PWRGOOD AB7 Async GTL+ Input TMS A25 TAP Input
REQ0# B19 Source Sync I/O TRDY# E19 Common Clk Input
REQ1# B21 Source Sync I/O TRST# F24 TAP Input
REQ2# C21 Source Sync I/O VCC A2 Power/Other
REQ3# C20 Source Sync I/O VCC A8 Power/Other
REQ4# B22 Source Sync I/O VCC A14 Power/Other
Reserved A26 Reserved Reserved VCC A18 Power/Other
Reserved D25 Reserved Reserved VCC A24 Power/Other
Reserved W3 Reserved Reserved VCC A28 Power/Other
Reserved Y3 Reserved Reserved VCC A30 Power/Other
Reserved AC1 Reserved Reserved VCC B6 Power/Other
Reserved AE15 Reserved Reserved VCC B20 Power/Other
Reserved AE16 Reserved Reserved VCC B26 Power/Other
Reserved AE28 Reserved Reserved VCC B29 Power/Other
Reserved AE29 Reserved Reserved VCC B31 Power/Other
RESET# Y8 Common Clk Input VCC C2 Power/Other
RS0# E21 Common Clk Input VCC C4 Power/Other
RS1# D22 Common Clk Input VCC C16 Power/Other
RS2# F21 Common Clk Input VCC C22 Power/Other
RSP# C6 Common Clk Input VCC C28 Power/Other
SKTOCC# A3 Power/Other Output VCC C30 Power/Other
SLP# AE6 Async GTL+ Input VCC D1 Power/Other
SLEW_CTRL AC30 Power/Other Input VCC D8 Power/Other
SMB_PRT AE4 Power/Other Output VCC D14 Power/Other
SMI# C27 Async GTL+ Input VCC D18 Power/Other
STPCLK# D4 Async GTL+ Input VCC D24 Power/Other
Table 21. Pin Listing by Pin Name (Sheet 3 of 8)
Pin Name
Pin
No.
Signal
Buffer Type
Direction Pin Name
Pin
No.
Signal
Buffer Type
Direction
