Intel Xeon Datasheet

Intel® Xeon™ Processor with 800 MHz System Bus
Datasheet 53
VCC D29 Power/Other VCC K1 Power/Other
VCC D31 Power/Other VCC K3 Power/Other
VCC E2 Power/Other VCC K5 Power/Other
VCC E6 Power/Other VCC K7 Power/Other
VCC E20 Power/Other VCC K9 Power/Other
VCC E26 Power/Other VCC K23 Power/Other
VCC E28 Power/Other VCC K25 Power/Other
VCC E30 Power/Other VCC K27 Power/Other
VCC F1 Power/Other VCC K29 Power/Other
VCC F4 Power/Other VCC K31 Power/Other
VCC F16 Power/Other VCC L2 Power/Other
VCC F22 Power/Other VCC L4 Power/Other
VCC F29 Power/Other VCC L6 Power/Other
VCC F31 Power/Other VCC L8 Power/Other
VCC G2 Power/Other VCC L24 Power/Other
VCC G4 Power/Other VCC L26 Power/Other
VCC G6 Power/Other VCC L28 Power/Other
VCC G8 Power/Other VCC L30 Power/Other
VCC G24 Power/Other VCC M1 Power/Other
VCC G26 Power/Other VCC M3 Power/Other
VCC G28 Power/Other VCC M5 Power/Other
VCC G30 Power/Other VCC M7 Power/Other
VCC H1 Power/Other VCC M9 Power/Other
VCC H3 Power/Other VCC M23 Power/Other
VCC H5 Power/Other VCC M25 Power/Other
VCC H7 Power/Other VCC M27 Power/Other
VCC H9 Power/Other VCC M29 Power/Other
VCC H23 Power/Other VCC M31 Power/Other
VCC H25 Power/Other VCC N1 Power/Other
VCC H27 Power/Other VCC N3 Power/Other
VCC H29 Power/Other VCC N5 Power/Other
VCC H31 Power/Other VCC N7 Power/Other
VCC J2 Power/Other VCC N9 Power/Other
VCC J4 Power/Other VCC N23 Power/Other
VCC J6 Power/Other VCC N25 Power/Other
VCC J8 Power/Other VCC N27 Power/Other
VCC J24 Power/Other VCC N29 Power/Other
VCC J26 Power/Other VCC N31 Power/Other
VCC J28 Power/Other VCC P2 Power/Other
VCC J30 Power/Other VCC P4 Power/Other
Table 21. Pin Listing by Pin Name (Sheet 4 of 8)
Pin Name
Pin
No.
Signal
Buffer Type
Direction Pin Name
Pin
No.
Signal
Buffer Type
Direction
