Intellian v240M User Manual

17
PLANNING INSTALLATION
Bolt Kit Components
Description Q'ty Size Remarks
Hex Bolt 4 M16 x 35L
Bolt Kit for Stable MountFlat Washer 4 M16
Spring Washer 4 M16
Hex Bolt 250 M6 x 35L Bolt for Radome Assembly
Flat Washer 500 M6(Ø18)
Washer & Nut for Radome &
Radome Base Assembly.
Spring Washer 250 M6
Nut 250 M6
Hex Bolt 10 M6 x 35L
Bolt Kit for Upper Radome Lift
Bracket
Flat Washer 20 M6(Ø18)
Spring Washer 10 M6
Nut 10 M6
Hex Bolt 9 M12 x 65L
Bolt Kit for Antenna Mounting
Flat Washer 17 M12
Spring Washer 9 M12
Nut 17 M12
Wrench Bolt 3 M10 x 35L
Bolt Kit for EL Support Bar
Wrench Bolt 5 M10 x 40L
Flat Washer 8 M10
Spring Washer 8 M10
Wrench Bolt 10 M10 x 35L
Bolt Kit for EL Weight PlateFlat Washer 10 M10
Spring Washer 10 M10
Wrench Bolt 28 M8 x 20L
Bolt Kit for EL Side PlateFlat Washer 28 M8
Spring Washer 28 M8
Wrench Bolt 5 M6 x 25L
Bolt Kit for Ku Module
Sems Bolt 3 M3 x 12L
Flat Washer 5 M6
Spring Washer 5 M6
Wrench Bolt 2 M8 x 70L
Bolt Kit for Reector Support
Pipe
Flat Washer 4 M8
Spring Washer 2 M8
Nut 2 M8
