Intellian v240M - Uncrating the Antenna

v240M – Marine Satellite Communication System
28
Uncrating the Antenna
Dismantling the Antenna Package
Remove all walls of the 3 crates (Radome Package, Antenna Package, and Frame
Package) using an impact drill.
Figure 14. Remove Walls of Radome Package
Figure 15. Remove Walls of Antenna Package
Ku Module Package Box
Ku Module Support Pipe
