v240M – Marine Satellite Communication System
84
BOW OFFSET EL.ADJUST
000 +0.0
7. Set the BOW OFFSET and EL. ADJUST
The BOW OFFSET function offsets the angle difference between the antenna’s bow and the
ship’s bow (Range: 0 – 360°). The EL. ADJUST function offsets the angle difference between
the mechanical elevation angle and actual elevation angle (Range: ± 5°).
Press the LEFT and RIGHT arrow keys until the desired character is underscored (selected).
Press the UP and DOWN arrow keys to increase and decrease the selected character.
Or press the NUMBER keys to set the desired value directly. Press the OK key to set the
parameter. Press the BACK key to select the parameter you wish to edit and press the BACK
key again to save or abort and return to the main display.
BOW & EL adjust
OPERATION
SAVE
8. Set OPERATION
Press the UP and DOWN arrow keys to select OPERATION items.
OPERATION*
• SAVE
• IDLE ON / OFF
• REBOOT
SAVE : save and execute the current settings.
The antenna is balanced at the factory. However, after disassembly for shipping,
maintenance or parts replacements, antenna balance adjustment may be
required.
The elevation and cross-level motors have a brake mechanism integrated into
them, therefore the antenna power and IDLE MODE must be ON to release the
motor brakes. Balancing is achieved by adding or removing weight blocks at
strategic locations to keep the antenna balanced.
IDLE MODE : Press the UP and DOWN arrow keys to turn ON / OFF IDLE
MODE. The motor brakes will be released while IDLE MODE is ON. The antenna
will restart automatically if IDLE MODE is re-set from ON to OFF or the BACK
key is pressed to exit SETUP mode.
REBOOT ANTENNA : The antenna will restart automatically if REBOOT
ANTENNA is ON.
