D-0134090-A – 2022/11
VisualEyes™ - Instructions for Use - EN Page 32
2.6.7 Rotary chairs (optional)
Several different rotary chairs can be added to the VisualEyes™
system.
The VisualEyes™
software supports below rotary chairs:
• Orion Reclining
• Orion Auto-Traverse
• Orion Comprehensive
• Nydiag 200
• System 2000 Reclining
• System 2000 Auto-Traverse
• System 2000 Comprehensive
For complete instructions for the hardware installation, please refer to the separate installation instructions.
Hardware setup:
1. Follow the instructions in the separate installation instructions for the specific rotary chair to set up
and connect the chair correctly.
2. Make sure the rotary chair is powered and connected to the PC.
3. Install the DAQ hardware driver according to the instructions in section 2.7: Installation of DAQ
hardware drivers for rotary chairs and DataLink.
4. Perform the rotary chair calibration and validation according to section 2.6.8.4: Rotary chair
calibration & validation.
