D-0134090-A – 2022/11
VisualEyes™ - Instructions for Use - EN Page 61
Main screen
When launching the VisualEyes™ software, it will start on the main screen (see Figure 3.2-1). The patient
information retrieved from OtoAccess® Database will be visible below the room camera image.
From the main screen there are several options:
1. Start Room Recording:
Clicking ”Start Room Recording” will start a recording from the external room camera. This can be
used to record a session with the patient before doing any measurements e.g. a patient interview.
This recording is linked to the selected patient.
2. Select Protocol:
The drop-down selection menu is used to set the protocol to be used in the patient session. For
further information on protocol management, refer to section 3.4.
3. Begin Testing:
Clicking ”BEGIN TESTING” will start the patient session with the selected protocol. For further
information on testing, see sections 3.8 and 3.9.
4. Patient Sessions:
This will take the operator to an overview of previous patient sessions that can be reviewed in detail,
exported, or printed. For further information see section 3.11.
5. Patient Videos:
Clicking on ”PATIENT VIDEOS” will take the operator to an overview of any previously recorded
patient videos. This includes both patient interviews and measurement recordings. For further
information see section 3.12.
6. Help:
The ”Help” button will open up the ”Instructions for Use” and ”Additional Information” documents.
These documents can also be found from the Windows File Explorer by navigating to ” C:\Program
Files (x86)\Interacoustics\Micromedical VisualEyes\Operation Manual”. This folder also contains
relevant quick guides.
7. Configuration:
This will take the operator to the settings menus. This includes Protocol Management, and System
Default Settings.
8. Exit:
The ”Exit” button will close the VisualEyes™ software.
9. Minimize:
The user can use the symbol to minimize the software for temporary access of other tasks in
the main screen.
