Interlogix NS3552-8P-2S-V2 User Manual

Chapter 4: Web configuration
192 NS3552-8P-2S-V2 User Manual
The page includes the following fields:
Object Description
Frame Type The settings in a particular row apply to the frame type listed here:
unicast
multicast
Broadcast
Enable Enable or disable the storm control status for the given frame type.
Rate The rate unit is packets per second (pps). Valid values are: 1, 2, 4, 8, 16, 32,
64, 128, 256, 512, 1K, 2K, 4K, 8K, 16K, 32K, 64K, 128K, 256K, 512K ,
1024K, 2048K, 4096K, 8192K, 16384K or 32768K.
Buttons
• Click Save to save changes.
• Click Reset to undo any changes made locally and revert to previously saved
values.
QoS statistics
The Queuing Counters page provides statistics for the different queues for all switch
ports.
