Chapter 4: Web configuration
NS3552-8P-2S-V2 User Manual 289
The page includes the following fields:
Object Description
Delete Select to delete the entry. It will be deleted during the next save.
ID Indicates the index of the entry. The range is from 1 to 65535.
Desc Indicates the event. The string length is from 0 to 127, default is a null string.
Type Indicates the notification of the event. The possible types are:
none: The total number of octets received on the interface, including framing
characters.
log: The number of unicast packets delivered to a higher-layer protocol.
snmptrap: The number of broadcast and multicast packets delivered to a
higher-layer protocol.
logandtrap: The number of inbound packets that are discarded when the
packets are normal.
Community Specify the community when trap is sent. The string length is from 0 to 127,
default is "public."
Event Last Time Indicates the value of sysUpTime at the time this event entry last generated
an event.
Buttons
• Click Add New Entry to add a new community entry.
• Click Save to save changes.
• Click Reset to undo any changes made locally and revert to previously saved
values.
RMON event status
The RMON Event Overview page provides an overview of RMON Event table entries.
Each page shows up to 99 entries from the Event table (default is 20 entries per page).
The range of entries per page can be typed into the Start from Control Index and
entries per page fields. When initially accessing the page, it shows the first 20 entries
from the beginning of the Event table. The first entry shown will be the one with the
lowest ID found in the Event table
