Interlogix NS3552-8P-2S-V2 User Manual

Chapter 4: Web configuration
304 NS3552-8P-2S-V2 User Manual
Ring wizard
Configure ERPS using a wizard on the Ring Wizard page.
The page includes the following fields:
Instance data
Object Description
All Switch Numbers Set all the switch numbers for the ring group. The default number is 3 and
maximum number is 30.
Number ID The switch where you are requesting ERPS.
Port Configures the port number for the MEP.
VLAN Set the ERPS VLAN.
Buttons
• Click Next to configure ERPS.
• Click Set to save changes.
• Click Save Topology to show the ring topology.
