Chapter 4: Web configuration
46 NS3552-8P-2S-V2 User Manual
IP v6 configuration
IP status displays the status of the IP protocol layer. The status is defined by the IP
interfaces, the IP routes, and the neighbour cache (ARP cache) status.
The page includes the following fields:
Object Description
Auto Configuration Select this check box to enable IPv6 auto-configuration. If the system cannot
obtain the stateless address in time, the configured IPv6 settings will be used.
The router may delay responding to a router solicitation for a few seconds. The
total time needed to complete auto-configuration can be significantly longer.
Address Provide the IPv6 address of this switch. IPv6 address is in 128-bit records
represented as eight fields of up to four hexadecimal digits with a colon
separating each field (:). For example, 'fe80::235:c5ff:fe03:4cd7'. The symbol
'::' is a special syntax that can be used as a shorthand way of representing
multiple 16-bit groups of contiguous zeros; but it can appear only once. It can
also represent a legally valid IPv4 address. For example, '::192.1.2.34'.
Prefix Provide the IPv6 Prefix of this switch. The allowed range is 1 to 128.
Router Provide the IPv6 gateway address of this switch. IPv6 address is in 128-bit
records represented as eight fields of up to four hexadecimal digits with a
colon separating each field (:). For example, 'fe80::235:c5ff:fe03:4cd7'. The
symbol '::' is a special syntax that can be used as a shorthand way of
representing multiple 16-bit groups of contiguous zeros; but it can appear only
once. It can also represent a legally valid IPv4 address. For example,
'192.1.2.34'.
Buttons
• Click Save to save changes.
• Click Reset to undo any changes made locally and revert to previously saved
values.
Users configuration
This page provides an overview of the current users. Close and reopen the browser to
log in as another user on the web server. After setup is complete, click the Apply
To Next Page
