Interlogix TruVision 6 Series User Manual

Installation Guide 27
Figure 3: IP fixed lens turret camera
9
9
8
7
7
2MPx / 4MPx8MPx
1. Lens assembly
2. Trim ring
3. Housing
4. Base
5. 12 VDC power
6. Ethernet RJ45 PoE
port
7. Reset button
8. Serial port (factory
use)
9. Micro SD card slot
Note: To reset the camera to default settings, press and hold
the RESET button and power on the camera. After the camera
has started up, hold the RESET button for an additional 20
seconds.
