Interlogix TruVision 6 Series User Manual

28 Installation Guide
Figure 4: IP motorized turret camera
15
16
17
1. Housing
2. Black rubber protective
cover
3. Rubber inserts
4. Removable cable
access door
5. Trim ring
9. Audio 1 input (line
in/mic in)
10. Audio 1 output (line
out)
11. GND for alarm output
12. Alarm 1 output (up to
12VDC, 30mA)
13. GND for alarm input

Interlogix TruVision 6 Series Specifications

General

Brand	Interlogix
Model	TruVision 6 Series
Category	IP Camera
Language	English
