Appendix A — Specifications
90 CK3 Mobile Computer User’s Manual
2D Symbologies Typical Reading Distances With 0.24 cm (0.09 in)
Setback*
Symbology Density Minimum Distance Maximum Distance
DataMatrix 0.25 mm (10 mils)
1.4 mm (55 mils)
2.5 mm (100 mils)
3.5 mm (140 mils)
5 mm (200 mils)
20.24 cm (7.96 in)**
20.24 cm (7.96 in)**
20.24 cm (7.96 in)**
20.24 cm (7.96 in)**
20.24 cm (7.96 in)**
73.76 cm (29.04 in)
339.76 cm (133.77 in)
679.76 cm (267.63 in)
789.76 cm (310.93 in)
1199.76 cm (472.02 in)
* Typical reading distances are measured in an office environment (200 lux).
** as long as the bar code label fits in the reading area
