Intermec EasyCoder PD41 Programmer's Guide

26 ZSim Programmer’s Guide
Keys: EasyCoder printers:
F2 decreases value of Y-position
F3 increases value of Y-position
PB50 printers:
increases value of Y-position
decreases value of Y-position
Clear Permanent
Purpose: Erases all formats and images stored in the
permanent memory of the printer.
Default Start Adjust
Purpose: Moves the origin towards or away from the edge
of the label by a certain distance before printing
starts. A positive start adjustment means that
the specified length of media will be fed out
before printing starts. A negative start
adjustment means that the specified length of
media will be pulled back before printing starts.
Default Stop Adjust
Purpose: Determines how much media feeds through
after printing is completed. This setting is used
to make sure that the labels are in the correct
position for tear off operation. This value can be
either positive or negative and is measured in
dots. A positive stop adjustment means that the
normal media feed is increased by the specified
value. A negative stop adjustment means that
the normal media feed is decreased by the
specified value.
Default: 0 dots (no adjustment)
Default:
Printer Model Start Adjust (dots)
PF2/4i, PM4i -100
PX4/6i -133
PD41 -80
PB50 0

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
