Intermec EasyCoder PD41 Programmer's Guide

ZSim Programmer’s Guide 35
^ID, ^IL, ^IM, ^IS
^JA, ^JC, ^JG, ^JL, ^JM, ^JP, ^JR, ^JU, ^JX, ^JZ
^LH, ^LL, ^LR, ^LS, ^LT
^MC, ^MD, ^MF, ^ML, ^MM, ^MN, ^MT, ^MU
^PH, ^PF, ^PO, ^PM, ^PQ, ^PR, ^PW
^SD, ^SN, ^SS, ^ST
^WC
^XA, ^XF, ^XG, ^XZ
Troubleshooting ZSim
If you have issues with the ZSim program on your printer, look
for the symptom in the next table and then try the suggested
solutions.
Issues and Solutions
Issue Solution
You change a value
in the Configuration
menu but the new
setting does not take
effect.
Press Enter or to save your changes.
If you press F2, Esc, or , the changes are
canceled and the value of the setting is not
changed.
You manually set the
Print Mode to Tear
Off, but once you
send a label to the
printer the setting
reverts to Rewind.
Check your print driver for its printer settings
and correct the Print Mode values. Some drivers
send down setup commands with their labels.

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
