ZSim Programmer’s Guide 11
What is ZSim?
ZSim is a Zebra™ interpreter program that interprets legacy ZPL
II or later programs on an Intermec EasyCoder PF2i, PF4i, PF4i
Compact Industrial, PM4i, PX4i, PX6i , PD41, PD42, or PB50
Mobile Label printer with Fingerprint. To use ZSim, you need to
load the ZSim program into the printer, configure a few settings,
and start sending Zebra commands. If the ZSim program was not
factory-installed, you can find it on the PrinterCompanion CD
or you can download it from the Intermec web site.
System Requirements
The printer must be equipped with a minimum of 8 MB of
DRAM.
Loading ZSim on the Printer
Depending on your printer model, you can load ZSim on the
printer using one of these methods:
• CompactFlash card (all EasyCoder printers)
• Intermec FieldInstaller (PB50 mobile printer)
Loading ZSim With a CompactFlash Card
You can load ZSim on the supported EasyCoder printers by
using a CompactFlash card. The card must meet these
requirements:
• Have at least 128 MB of available free space
• Be formatted with FAT or FAT 16, but not FAT 32
Hardware and Firmware Requirements
Printer Models Fingerprint Version ZSim Version
EasyCoder
PF2i, PF4i, PF4ci
PM4i
PX4i, PX6i
8.70.1 or later 5.14 or earlier
EasyCoder PD41 10.0.0 or later 5.14 or earlier
EasyCoder PD42 10.2.1 or later 5.15 or later
PB50 11.1.1 or later 5.14 or later

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
