Intermec EasyCoder PD41 Programmer's Guide

ZSim Programmer’s Guide 29
Optimize Bar Code Magnification
Purpose: This setting compensates for size differences
when a 300 dpi Zebra printer is replaced by an
Intermec printer with a 203 dpi printhead. If
the bar code ends up being too small, increase
the value of this parameter to manually enlarge
the x-dimension. Valid values are 0 to 9.
Default: 0 (no magnification)
Optimize Batch
Purpose: To obtain higher performance during batch
printouts.
Default: On
Optimize Image Magnification
Purpose: If the Intermec printhead is not the same
resolution as the original Zebra printhead,
images may not print correctly. If you want to
increase the size of printed images, you can
adjust this with the function On/Off.
Default: Off
Paper Type
Purpose: Sets the type of paper used in the printer. You
can set this command to Thermal Transfer or
Direct Thermal. Set this parameter during the
Initial Setup Configuration process.
Note: When replacing a Zebra printer, choose an
Intermec printer with the same printhead
resolution. However, if you are replacing a 152
dpi Zebra printer, use an Intermec printer with a
300 dpi printhead.
Note: When replacing a printer, choose a printer
with the same printhead resolution. However, if
you are replacing a 152 dpi printer, use an
Intermec printer with a 300 dpi printhead.

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
