Intermec EasyCoder PD41 Programmer's Guide

16 ZSim Programmer’s Guide
Configuring ZSim on the PD41
ZSim on the PD41 works a bit differently because the printer
only has one key and does not have a liquid crystal display
(LCD).
Configuring ZSim Using Text File Download
Text file configuration is the preferred method to configure a
PD41, but parameters can be set on any printer by downloading
a text file to the printer with the following format:
^ZX[ParamName,]ParamNo,ParamValue^FS
Use the following table to understand the commands required for
setting the parameters. The table also contains a few commands
for making setup changes. To make sure that the update is secure,
download and execute the commands one at a time. You can
verify that the update has been completed correctly by printing a
configuration label.
Standard PD41 Key Functions
Action Description
FEED Key press < 1 second, when ZSim is idle
CALIBRATE & Key press 1 to 4 seconds, when ZSim is idle
CONFIG LABEL Terminates calibration
BREAK ZSIM Key press 5 to 10 seconds, when ZSim is idle
PAUSE-batch Key press < 1 second when ZSim is printing,
EXIT with same process
CANCEL-batch Key press > 1 second when ZSim is in PAUSE-
batch mode
Note: The default instruction prefix (^) and the
default delimiter (,) are used in the samples at the end
of this section.

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
