Intermec EasyCoder PD41 Programmer's Guide

ZSim Programmer’s Guide 31
Redo Config
Purpose: Removes the configuration file and reboots the
printer. The ZSim Initial Setup Configuration
Menu appears when the printer restarts. This
command requires access to the Fingerprint
Setup menu. You will be prompted to enter the
Fingerprint password before you can access this
command.
Reset Tuning
Purpose: Returns all Media Tuning parameters to their
original (default) values.
Save Current
Purpose: Saves the current ZSim configuration
parameters for future use.
Select Character Set
Purpose: Allows the user to block any ^CIa (change
international font) command from host. For
example, if you enter 1257 (Windows Baltic
Rim), the corresponding character set will be
valid whichever international font is
downloaded. If you Clear the field, ZSim will
parse the ^CI command again.
Simulation Resolution
Purpose: Sets the resolution of the Zebra printer being
simulated. You can set this command to 152
dpi, 203 dpi, or 300 dpi.
Default: 203 dpi (with 203 dpi printhead)
300 dpi (with 300 dpi printhead)
Note: Differences in resolution may cause
degradation of bar code quality. See “Optimize
Bar Code Magnification” on page 29 for more
information on adjusting the resolution.

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
