Intermec EasyCoder PD41 Programmer's Guide

30 ZSim Programmer’s Guide
Peel Off Length
Purpose: Sets the default distance the label should stop
before the tear off bar when the printer is in Peel
Off mode. Distance is measured in dots.
Permanent Save
Purpose: Stores all downloaded formats and images in the
printer’s memory. The next time the printer
starts up, saved formats and images are loaded
and ready for use. Turning Permanent Save off
does not delete saved items, but they are not
loaded automatically when the printer starts up.
Default: Off
Print Configuration Label
Purpose: Prints the current ZSim configuration settings
on a label.
Print Mode
Purpose: Determines the printer operating mode and sets
the label origin to suit the corresponding mode:
Tear Off, Peel Off, Cutter, or Rewind.
Default: Te a r Of f
Default Peel Off Lengths
PB50 PD41 PF2/4i PM4i PX4/6i
203 DPI Printhead 60 44 44 44 60
300 DPI Printhead N/A 60 66 60 100
Note: If you are downloading your graphics or
formats as you print, turn off Permanent Save to
increase processing speed.

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
