Chapter 1 — Getting Started
6 IF30 Fixed Reader User’s Manual
Understanding the LEDs
The IF30 has three LEDs that show you the operating status of
the reader.
IF30 LEDs
LEDs
LED Descriptions
LED Icon LED Name Description
Power Remains on after the IF30 boots.
Wired LAN Flashes when a frame is transmitted
or received on the Ethernet port.
Intermec
Ready-to-Work™
Indicator
Blue LED remains on when an
application is communicating with
the data collection engine (DCE) on
the IF30. Blinks when no application
is communicating with the DCE. For
more information, see the next
section.
