Chapter 1 — Getting Started
18 IF30 Fixed Reader User’s Manual
Installing the IF30
This section explains how to choose a mounting location for the
IF30 and connect the IF30 to your wired Ethernet network.
Choosing a Mounting Location
You can place the IF30 horizontally or vertically on a stable
surface. You can also mount the IF30 to a wall or a beam using
one of these mounting bracket kits:
• Mounting bracket kit (P/N 068918)
• Rotating mounting bracket kit (P/N 068751)
For more information, contact your local Intermec
representative.
Mounting the IF30: This illustration shows the ways you can install the IF30
on a horizontal or vertical surface.
The next table includes environmental requirements for the
IF30. Choose a location that meets these requirements.
Wall
IF30 Environmental Requirements
Type Minimum Maximum
Operating temperature -25ºC (-13ºF) 55ºC (131ºF)
Storage temperature -30ºC (-22ºF) 75ºC (167ºF)
Humidity (non-condensing) 10% 90%
