Intermec PW50

Appendix A — Specifications
PW50 Workboard Printer User Guide 37
When you order printer media, keep these points in mind:
• You can use higher caliper media in the printer, but print quality
will be reduced.
• Receipt roll stock media is supplied as a continuous roll and has
an end of roll indicator. The end of roll indicator is a red marking
(on last 3 feet of roll) on the thermally sensitive side of the paper.
Print Speed and Resolution
Specification Value
Print speed 4 ips (100 mm/s)
Resolution 203 dpi (8 dots/mm)
Print Technology
Technology Description
Printhead Direct thermal
Maximum print width 108 mm (4.25 in)
Media Specifications
Media Value
Core inside diameter, standard 19 mm (0.75 in)
Core inside diameter, with adapter 10.2 mm (0.4 in)
Maximum roll outside diameter 67.3 mm (2.65 in)
Media width, receipt 111.5 mm (4.4 in)
Media length, receipt Continuous
Media caliper, receipt 0.05 mm (0.002 in) to
0.165 mm (0.0065 in)
