Service Manual Invacare
®
Electra
As at: 15.04.02 Page 11
Item: Checks OK
Defec
t
Remedy
4.0 Drive unit:
4.1 Check functioning and smooth running of motor and gearbox
4.2 Check motor clutch for push mode
4.3 Check connection between drive unit and chassis for tight fit
4.4
Check condition and tight fit of all cables and connecting
plugs
Replacing components
chapt.: 9.6 page: 23
4.5 Check wheels for tight fit
4.6 Check wheel rims for damage and side play
4.7 Check tyres for wear and damage
Replacing components
chapt.: 9.6 page: 23
5.0 Batteries:
5.1
Check condition and tight fit of all cables and connecting
plugs
5.2 Check batteries for damage
5.3 Check battery condition
5.4 Check battery contacts
Replacing components
chapt.: 10.1 page: 26
5.5 Check battery voltage Chapt.: 11.1 page: 31
6.0
Operating unit
6.1 Check operating unit for damage.
6.2 Check operating unit pilot lights for correct functioning
6.3 Check drive lever for correct functioning
6.4
Check operating unit displays and controls for correct
functioning
6.5 Check drive disabler and lock for correct functioning
Chapt.: 10.2 page: 28
7.0 Controller:
7.1
Check condition and tight fit of all cables and connecting
plugs
Replace defective
cables
7.2 Check controller for damage
Replacing defective
components see
chapt.: 10.1 page: 26
8.0 General
8.1 Retighten all holders and screws
8.2
Trial run with examination of drive parameters (acceleration /
speed in bends / braking behaviour)
