12.2.2 Connecting the programming device
• Switch off the Scooter.
• Remove the chassis panelling (see chapter 9.3 page: 19).
• Remove the cover cap (1) next to the remote plug on the controller.
• Plug the hand programming device connector plug into the socket.
• Switch on the Scooter.
• To program the Scooter, see the programming device operating manual.
Remove the cover cap
Note:
The connector plug also attached to the programming device for the charging socket cannot
be used for programming the Scooter.
Removing the programming device
• Switch off the Scooter.
• Remove the hand programming device connector plug from the socket.
• Replace the cover cap.
• Complete the Scooter.
