Invacare electra - 7 Maintenance Plan

Invacare
®
Electra Service Manual
Page 10 As at:15.04.02
7 Maintenance plan
Carry out an inspection on the Scooter using the maintenance plan. You can make this inspection easier by
copying the maintenance plan and noting any defects found in the plan.
Item: Checks OK
Defec
t
Remedy
1.0 Seat:
1.1
Check armrest for damage and tight fit (pay special attention
to welded seams)
1.2
Check folding mechanism for armrests (ease of movement,
no play in joints)
1.3 Check armrest width adjustment correct functioning.
1.4
Check backrest and backrest frames for damage and tight fit
(pay special attention to welded seams)
1.5 Check backrest height adjustment for correct functioning.
1.6
Check seat and seat frames for damage and tight fit (pay
special attention to welded seams)
1.7 Check seat support tube for damage.
1.8
Check seat unit rotation and unlocking lever for correct
functioning.
Replacing components
chapt.: 9.1 page: 14
2.0 Steering:
2.1 Check all steering column components for damage.
Replacing components
chapt.: 9.2 page: 17
2.2
Check steering column folding mechanism for correct
functioning.
2.3 Check folding joint teeth for damage.
Replacing components
chapt.: 9.2 page: 17
3.0 Chassis:
3.1
Check frames for damage and deformation (pay special
attention to welded seams)
3.2 Check panelling for damage
3.3 Check reflectors for damage
3.4
Check steering had bearings for smooth running and zero
backlash.
Replacing components
chapt.: 9.3 Page 19
3.5 Check wheel rims for damage and side play
3.6 Check tyres for wear and damage
Replacing components
chapt.: 0 page: 21
3.7 Anti-tipper:
3.7.1 9Check all anti-tipper components for damage.
3.7.2 9 Check track rollers for smooth running.
Replacing components
chapt.: 9.3 page: 19
