SECTION 7—COMPRESSOR
Perfecto
2
™
40 Part No 1148070
Compressor
 WARNING
Toavoidpersonalinjuryorpropertydamage,rotatethefanbyhandpriortoconnecting
theunittoapowersource.Checkforsuctionattheairinletbyplacingyourfingerover
theportasyourotatethefan.Youshouldfeelaslightsuctionwitheachrotationofthe

fan.IfyouDONOTfeelasuctionbutyoufeelorhearathumpasyouturnthefan,DO
NOTconnecttheunittoapowersource.Reviewtheassemblyprocedureforpossible
error.
NOTE:Forthisprocedure,refertoFIGURE 7.7onpage 41.
1. Reinstallcompressor.RefertoReplacingCompressorAssemblyonpage 31.
2. Rununitandcheckforleaksaroundcompressorhosesandcompressortubes.Refer
toLeakTestonpage 76.
3. Takepressurereadingstoensurepropersystempressures.RefertoCheckingSieve
BedPressureonpage 86.
FIELD SERVICE PARTS LIST FOR THOMAS 2660 SERIES COMPRESSOR
2660CE37-989 COMPRESSOR
ITEM
NO.
PART
NO.
QTY.
PER ASM
QTY.
PER UNIT DESCRIPTION
1 See Chart — 2 Connecting Rod, Eccentric & Bearing Assembly
2 624277 1 2 Piston Cup
3 625776 1 2 Screw - Piston Cup Retainer
4 626175 1 2 Piston Cup Retainer
5 618114 1 2 Cylinder Sleeve
6 See Chart — 1 Head
7 623143 — 2 O-Ring - Head Gasket
8 625175 — 8 Screw - Head
9 621591 — 2 Valve Plate Assembly
638574 — 1 Valve - Pressure Relief-Not Shown (115 V)
10 617177 1 2 Valve Restraint
11 617562 2 4 Valve Keeper Strip
12 621485 2 4 Valve Flapper - Intake & Exhaust
13 621641 1 2 Valve Plate
14 625094 2 4 Screw - Valve Flapper
15 623137 — 2 O-Ring Valve Plate
16 638281 — 1 Fan - Gray
17 638282 — 1 Fan - Black
ITEM PART NO. QTY. DESCRIPTION
1 607731 2 Connecting Rod, Eccentric & Bearing Assembly
6 665167 1 Head
