SECTION 14—COOLING FAN
Perfecto
2
™
56 Part No 1148070
15. Connectspadeconnectorstofanterminalsonsideofcoolingfan(Detail“B”).
16. Moveresonatorhousingbackintoposition(Detail“A”).
17. Securetheresonatorhousingtothesoundboxwiththethreemountingscrews.Twoin
thetopandoneonthebacknearthebottomofthehousing(Detail“A”).
18. ifnecessary,reconnecttheintakevalveonthecompressorassembly.
19. Reinstallcontrolpanel.RefertoRemovingControlPanelonpage 53.
20. ReinstallcompressorinletHEPAfilter.RefertoReplacingtheCompressorInletHEPA
Filteronpage 26.
21. Plugunitinandcheckforleaks.RefertoLeakTestonpage 76.
22. Rununitforatleast30minutes.Ifunitrunsproperly,replacecover.Ifnot,call
InvacareTechnicalService.
23. Reinstallcabinet.RefertoCabinet
onpage 23.
