SECTION 20—4-WAY VALVE/MANIFOLD ASSEMBLY
Part No 1148070 69 Perfecto
2
™
12. Installnewslottedpoppetintothebottomofthepilotvalvestemwithtaperedend
facingtothebottom.
13. Installpilotvalvestemandnewslottedpoppetwithcoil(withyokeandlocknut
intact)intomanifoldopening.
14. Useaflatbladescrewdriver,andtightenpilotvalvestemclockwiseuntilsnug.Torque
to25inch‐lbs.±5inch‐lbs.
15. Installnewlabelontopilotvalvecoilyoke.
16. Positionpilotvalvecoilwithyokeatanapproximate90°angletotherightasviewed
fromthefrontofvalve.
17. Usetheflatbladescrewdriverandholdthepilotvalve‐steminplace.
18. Tightenlocknutclockwisewiththe9/16‐inchwrenchuntilsnugtosecurethestemand
coilwithyoke.DONOTovertighten.Torqueto20inch‐lbs±3inch‐lbs.
CAUTION
DONOTovertightenlocknutwheninstallingitontopilotvalvestem.Damagetothe
plasticmanifoldmayoccur.
19. PlugpowercordinandturnconcentratorON(I)toensureproperoperation.
20. Reinstallcabinet.RefertoRemovingCabinetonpage 23.
21. Ifanydifficultiesareencounteredinthisinstallation,contactInvacareTechnical
Serviceat(800)832‐4707.
