Invacare®TDX®SP2Series
Adequatemobilityandupperbodystrengthis
requiredtoperformthisactivityindependently.
1.Transfertoandfromthewheelchairinthepresence
ofaqualiedhealthcareprofessionaltodetermine
individualsafetylimits.
2.TurnpowerbuttonOFFBEFOREenteringorexitingthe
wheelchair.
3.ReducegapbetweentransfersurfaceBandwheelchair
seatCtotheminimumdistanceAnecessaryto
performtransfer.
4.ALWAYSensurebothmotorlocksareengagedand
wheelhubs(ifequipped)topreventthewheelsfrom
movingbeforetransferringintoorfromthewheelchair.
5.Aligncastersparalleltothedrivewheelstoimprove
stabilityduringtransfer.
6.Invacarestronglyrecommendsorderingtheoptional
wheellocksasanadditionalsafeguardifnotpresent.
7.Flipupfootplatesorswingfootrestsoutward.
8.Shiftbodyweightintoseatwithtransfer
Duringindependenttransfer,littleornoseat
platformwillbebeneathyou.Useatransfer
boardifatallpossible.
2.5PinchPoints
WARNING!
RiskofMinortoSeriousInjury
Pinchpointscancauseminortoseriousinjury.
–Bemindfulofpotentialpinchpointsanduse
cautionwhenusingthisproduct.
WARNING!
RiskofInjury
Pinchpointscancauseinjury.
–BeawarethatapinchpointAexistsbetween
theheadtubecapandwalkingbeam.
–BeawarethatapinchpointBexists
betweenthewalkingbeam/headtubecapand
telescopingtubewhenthewheelchairisatthe
lowestseattooorheight.
–BeawarethatapinchpointCmayoccur
whenrotatingthecentermountfrontrigging
assembly.
Fig.2-12PinchPoints—Head
TubeCap/WalkingBeamand
TelescopingTube
Fig.2-13PinchPoints—Center
MountFrontRigging
