Invacare®TDX®SP2Series
4Components
4.1ComponentOverview
Fig.4-1
ITEMDESCRIPTION
A
BackCushion
B
Armrest
C
Remote(Joystick)
D
SeatCushion
E
DriveWheel
F
Fork
GCaster
H
FrontRigging
I
BackCane
J
Headrest
4.2Remotes
Remotesincludejoysticksandotherdevicesusedtodrive
thepowerwheelchair,operatethepoweredseatingsystem
oroperateotherfunctions.Yourpowerwheelchairmay
beequippedwithoneofseveraldifferentremotes.For
informationonthedifferentfunctionsandhowtooperate
aparticularremote,refertoitscorrespondingusermanual
(enclosed).
4.3ThePoweredSeatingSystem
Thepoweredseatingsystemisoperatedfromtheremote.
Refertotheremotemanualformoreinformation.
Thepoweredseatingsystemmayincludethefollowing
functions,dependingonthemodulesinstalled:
