Invacare TDXSP2 - Installing Batteries into the Wheelchair

Invacare®TDX®SP2Series
Fig.7-6
1.Placethewheelchairinawellventilatedarea.
2.VerifytheremoteOn/OffswitchisintheOffposition
anddisconnectbyunpluggingthecablefromthe
remote.
Removetherearshroud,frontshroudandbattery
retentionbracket.Referto9.6Removing/Installingthe
Shrouds,page70.
3.Disconnectthecontrollerfromthebatteriesattherear
ofthewheelchair.
4.RemovethefourmountingscrewsAsecuringthe
batterytrayBtotheframeC.
5.Slidebatterytraywithbatteriesout.
6.DisconnectthebatterystrapsD.
BatteryconnectionElocatedontop.
7.Disconnectbatteries.
8.RemovethefrontFbattery.
9.SlidetherearbatteryGforwardandremoveitfrom
thetray.
7.2.13InstallingBatteriesintotheWheelchair
WARNING!
RiskofSeriousInjury
Improperlyinstalledbatterytraycancause
instabilityresultinginseriousinjury.
–Ensurebatteriesandbatterytrayareinstalled
properlytomaintainstability.
5260101831-A
