Invacare®TDX®SP2Series
1.LoosenleverA.
2.Shiftmidlineholdertodesiredposition.
3.Tightenlever.
AdjustingJoystickontheJoystickMount
•5/32”(4mm)Allenkey
Fig.5-3
1.LoosenscrewA.
2.Positionjoystickonholder.
3.Tightenscrew.
Withoneturnofthescrew,thejoystickcanbe
rotatedinacomplete360degreeradius.Thereis
aslotonthesidethatwillallowyoutoanglethe
joystickat90degrees.
4060101831-A
