ControlsSystem
WARNING!
Riskofshortcircuitandelectricshockifthe
batterychargerhasbeendamaged
–Donotusethebatterychargerifithasbeen
droppedordamaged.
WARNING!
RiskofInjury,DamageorDeath
Improperroutingofcord(s)maycausetripping,
entanglementorstrangulationhazardthatmay
resultininjury,damageordeath.
–Ensureallcord(s)areroutedandpositioned
properlywhilecharging.
–Avoidpositioningcord(s)acrossareasofhigh
foottrafc(i.e.aisles,doorways,hallways,etc.)
whilecharging.
–Closesupervisionandattentionisneededwhen
operatingthewheelchairnearchildren,petsor
peoplewithphysical/mentaldisabilities.
1.Performoneofthefollowing
•ChargingNEWbatteries—Ensurethemobility
devicepowerisON.
Thewheelchairpowermustbeontoensure
thataccuratebatterychargelevelsdisplay
ontheremote.Newbatteriesmustbe
chargedfully.TheBatterySynchronization
ProcedureMUSTbeperformedwithin24
hoursofpoweringonthewheelchair.The
BatterySynchronizationProcedurecanbe
foundintheLiNXservicemanualandmust
beperformedbyaproviderorqualied
technician.
•Chargingexistingbatteries—Switchoffthemobility
device.
2.Connectthebatterychargertothechargersocket.
Thechargerconnectorpinsareidentiedinthe
followingways:
Fig.7-1
•Pin1A—BatteryPlus(+)
•Pin2B—Battery(-)
•Pin3C—Inhibit
3.Connectthebatterychargertothepowersupply.
