ControlsSystem
Failuretousethecorrectbatterysizeand/orvoltage
maycausedamagetoyourwheelchairandgive
youunsatisfactoryperformance.Thewarrantyand
performancespecicationscontainedinthismanual
arebasedontheuseofdeepcyclegelcellbatteries.
Invacarestronglyrecommendstheiruseasthe
powersourceforthisunit.
Carefullyreadbattery/batterychargerinformationpriorto
installing,servicingoroperatingyourwheelchair.
1.Positionbatteryonground/atsurfaceasshownbelow.
2.Visuallyinspectthebatterytoensureproperpolarity:
FORWHEELCHAIRSUSING22NFBATTERIES
Batterieswithterminalconguration(POSITIVEAon
theleftandNEGATIVEBontheright)asshownbelow
MUSTbeused.Batteriesthathavethereverseterminal
congurationMUSTnotbeused-otherwiseinjuryand
damagemayoccur.
TerminalsmustbehaveacrossholeCinthemasshown
below.
PROPERBATTERIESTOUSE
DONOTUSETHISTYPE
OFBATTERY
Fig.7-2 Fig.7-3
FORWHEELCHAIRSUSINGGP24BATTERIES
Batterieswithterminalconguration(POSITIVEAon
therightandNEGATIVEBontheleft)asshownbelow
MUSTbeused.Batteriesthathavethereverseterminal
congurationMUSTnotbeused-otherwiseinjuryand
damagemayoccur.
TerminalsmustbehaveacrossholeCinthemasshown
below.
60101831-A
47
