Invacare®TDX®SP2Series
Batteries
•Number:2
•Type:GP24or22NF
•Chemistry:SealedVRLAGel
•OperatingVoltage:24Vnominal(2x12V)
•GP24Batteryweight:approx.52lbs(23.6kg)perbattery
•22NFBatteryweight:approx.37lbs(16.8kg)perbattery
•GP24Amp-HourRating:73.5Ah(C20)(63Ah(C5))
•22NFAmp-HourRating:50Ah(C20)(43.2Ah(C5))
•Fuse:125A
Degreeofprotection
1
•PowerWheelchairBase—IPX4
•Charger—IPX1
Drivewheels•Blackwithriminserts,14x3”
•Blacktireswithgelfoaminsertsorpneumatictires
Therecommendedmaximumtirepressureinbarorkpaismarkedon
thesidewallofthetireortherim.Ifmorethanonevalueislisted,the
loweroneinthecorrespondingunitsapplies.
(Tolerance=-0.3bar,1bar=100kpa)
ForksSingleanddoublesidedforks
Casters
•Black,6x2”
•Punctureproof
Drivingcharacteristics
MaximumSpeed
•5.8mph(9.3km/h)
Minimumbrakingdistance
•5.8mph(9.3km/h):45.7–69.3in(1161–1760mm)
Minimumbrakingtime
•5.8mph(9.3km/h):1.39sec
7860101831-A
