Optidrive ODV-2 User Guide Revision 2.00
Declaration of Conformity:
Invertek Drives Limited
Offas Dyke Business Park
Welshpool
Powys
UK
SY21 8JF
Invertek Drives Ltd hereby states that the Optidrive ODV-2 product range conforms to the relevant safety provisions of the Low Voltage
Directive 2006/95/EC and the EMC Directive 2004/108/EC and has been designed and manufactured in accordance with the following
harmonised European standards:
Adjustable speed electrical power drive systems. Safety requirements. Electrical, thermal and energy.
Adjustable speed electrical power drive systems. EMC requirements and specific test methods
Limits and Methods of measurement of radio disturbance characteristics of industrial, scientific and
medical (ISM) radio-frequency equipment (EMC)
Specifications for degrees of protection provided by enclosures
Electromagnetic Compatibility
All Optidrives are designed with high standards of EMC in mind. All versions suitable for operation on Single Phase 230 volt and Three Phase
400 volt supplies and intended for use within the European Union are fitted with an internal EMC filter. This EMC filter is designed to reduce
the conducted emissions back into the supply via the power cables for compliance with harmonised European standards.
It is the responsibility of the installer to ensure that the equipment or system into which the product is incorporated complies with the EMC
legislation of the country of use. Within the European Union, equipment into which this product is incorporated must comply with the EMC
Directive 2004/108/EC. When using an Optidrive with an internal or optional external filter, compliance with the following EMC Categories, as
defined by EN61800-3:2004 can be achieved:
1 Phase, 230 Volt Input
ODV-2-x2xxx-1xFxx-xx
No additional filtering required
Use shielded motor cable
3 Phase, 400 Volt Input
IP20 & IP66 Models
ODV-2-x4xxx-3xFxx-xx
Use Additional External Filter
No additional filtering required
3 Phase, 400 Volt Input
IP55 Models
ODV-2-x4xxx-3xFxN-xx
Use Additional External Filter
No Additional Filtering Required
3 Phase, 525 & 600 Volt Input
All Models
ODV-2-x5xxx-3x0xx-xx
ODV-2-x5xxx-3x0xx-xx
This equipment is intended for fixed installation, and is not intended to conform to the EMC Directive
without additional preventative measures being applied. Consult your Invertek Sales Partner for further
information.
Compliance with EMC standards is dependent on a number of factors including the environment in which the drive is installed,
motor switching frequency, motor, cable lengths and installation methods adopted.
For motor cable lengths greater than 100m, an output dv / dt filter must be used, please refer to the Invertek Stock Drives
Catalogue for further details
All rights reserved. No part of this User Guide may be reproduced or transmitted in any form or by any means, electrical or mechanical
including photocopying, recording or by any information storage or retrieval system without permission in writing from the publisher.
Copyright Invertek Drives Ltd © 2013
All Invertek Optidrive HVAC units carry a 2 year warranty against manufacturing defects from the date of manufacture. The manufacturer
accepts no liability for any damage caused during or resulting from transport, receipt of delivery, installation or commissioning. The
manufacturer also accepts no liability for damage or consequences resulting from inappropriate, negligent or incorrect installation, incorrect
adjustment of the operating parameters of the drive, incorrect matching of the drive to the motor, incorrect installation, unacceptable dust,
moisture, corrosive substances, excessive vibration or ambient temperatures outside of the design specification.
The local distributor may offer different terms and conditions at their discretion, and in all cases concerning warranty, the local distributor
should be contacted first.
This user guide is the “original instructions” document. All non-English versions are translations of the “original instructions”.
Contents of this User Guide are believed to be correct at the time of printing. In the interest of a commitment to a policy of continuous
improvement, the manufacturer reserves the right to change the specification of the product or its performance or the contents of the User
Guide without notice.
This User Guide is for use with version 1.30 Firmware.
User Guide 2.00
Invertek Drives Ltd adopts a policy of continuous improvement and whilst every effort has been made to provide accurate and up to date
information, the information contained in this User Guide should be used for guidance purposes only and does not form the part of any
contract.
