INVT BPD1K5TNAC User Manual

BPD series PV pumping inverter Function parameters
24
Function
code
Name
Detailed description
Default
Modify
P00.01
Run command
channel
Select the run command channel of the inverter.
The control command of the inverter includes:
start, stop, forward/reverse rotating, jogging and
fault reset.
0: Keypad running command
channel("LOCAL/REMOT" light off)
Carry out the command control by RUN,
STOP/RST on the keypad.
Set the multi-function key QUICK/JOG to
FWD/REVC shifting function (P07.02=3) to
change the running direction; press RUN and
STOP/RST simultaneously in running state to
make the inverter coast to stop.
1: Terminal running command channel
("LOCAL/REMOT" flickering)
Carry out the running command control by the
forward rotation, reverse rotation and forward
jogging and reverse jogging of the multi-function
terminals
2: Communication running command channel
("LOCAL/REMOT" on);
The running command is controlled by the upper
monitor via communication
0
○
P00.03
Max. output
frequency
This parameter is used to set the maximum output
frequency of the inverter. Users need to pay
attention to this parameter because it is the
foundation of the frequency setting and the speed
of acceleration and deceleration.
Setting range: P00.04–400.00Hz
50.00Hz
◎
P00.04
Upper limit of
the running
frequency
The upper limit of the running frequency is the
upper limit of the output frequency of the inverter
which is lower than or equal to the maximum
frequency.
Setting range: P00.05–P00.03 (Max. output
frequency)
50.00Hz
◎
