INVT BPD1K5TNAC User Manual

BPD series PV pumping inverter Product overview
5
2 Product overview
2.1 Product specifications
Model
BPD0K7
TN(AC)
BPD1K5
TN(AC)
BPD2K2
TN(AC)
BPD004
TNAC
BPD2K2
TRAC(S)
BPD004
TRAC(S)
BPD5K5
TRAC(S)
DC input
Maximum DC
voltage (V)
450
800
Starting voltage
(V)
80
100
220
Minimum
working voltage
(V)
60
80
180
Recommended
MPPT voltage
(V)
80–400
100–400
220–750
Number of
input channels
1/MC4
connector
2/MC4 connector
1/MC4
connector
2/MC4 connector
Maximum input
DC current (A)
9
12
12
20
12
20
20
Bypass AC input (supporting mains input)
Input voltage
(V AC)
220/230/240(1PH) (-15%–+10%)
380 (3PH) (-15%–+10%)
Input frequency
(Hz)
47–63
AC input
terminal
L, N, PE
R, S, T, PE
AC output
Rated power
(W)
750
1500
2200
4000
2200
4000
5500
Rated current
(A)
5.1 (1PH)
4.2 (3PH)
10.2
(1PH)
7.5 (3PH)
14 (1PH)
10 (3PH)
25 (1PH)
16 (3PH)
5.5
9.5
14
Output voltage
(V AC)
0–Input voltage
