BPD series PV pumping inverter Function parameters
23
3 Function parameters
For the convenience of function codes setting, the function group number corresponds
to the first level menu, the function code corresponds to the second level menu and the
function code corresponds to the third level menu.
1. Below is the instruction of the function lists:
The first column "Function code": codes of function parameter group and parameters;
The second column "Name": full name of function parameters;
The third column "Detailed description": detailed illustration of the function parameters;
The forth column "Default": original factory settings of the parameters;
The fifth column "Modify": the modifying character of function codes (the parameters
can be modified or not and the modifying conditions), below is the instruction:
"○": means the set value of the parameter can be modified on stop and running state;
"◎": means the set value of the parameter cannot be modified on the running state;
"●": means the value of the parameter is the real detection value which cannot be
modified.
(In order to avoid mistakes, the modify attribute of each parameter is limited by the
inverter)
3.1 Parameters of common functions
P00 Group Basic function group
0: SVC 0
No need to install encoders. Suitable in
applications which need low frequency, big torque
for high accuracy of rotating speed and torque
control. Related to mode 1, it is more suitable for
the applications which need small power.
1: SVC 1
1 is suitable in high performance cases with the
advantage of high accuracy of rotating speed and
torque. It does not need to install pulse encoder.
2: SVPWM control
2 is suitable in applications which do not need high
control accuracy, such as the load of fan and
pump. One inverter can drive multiple motors.
