BPD series PV pumping inverter Product overview
16
H3 H2
W2
W1
H1
D
Figure 2.8 Dimensions of BPD2K2–5K5TRAC(S)
(Unit: mm)
Model
H1
W1
D
H2
W2
H3
Installation
Hole
BPD2K2TRAC(S)
331
360
154.5
122.5
260
45
8
BPD004TRAC(S)
454
360
154.5
184
260
45
8
BPD5K5TRAC(S)
454
360
154.5
184
260
45
8
2.7 Keypad operation procedure
2.7.1 Keypad introduction
The keypad is used to control the PV pumping inverter, read the state data and adjust
parameters.
1
2
4
3
5
RUN/TUNE FWD/REV LOCAL/REMOT TRIP
RPM
H
2
A
V
%
PRG
ESC
DATA
ENT
QUICK
JOG
SHIFT
RUN
STOP
RST
Figure 2.9 External keypad
