INVT GD270-090-4 User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-98-
Function
code
Name Description Default
7: Frequency level detection FDT2
8: Frequency reached
9: Running in zero speed
10: Upper limit frequency reached
11: Lower limit frequency reached
12: Ready for running
13: Pre-exciting
14: Overload pre-alarm
15: Underload pre-alarm
16: Simple PLC stage completed
17: Simple PLC cycle completed
18: Set counting value reached
19: Designated counting value reached
20: External fault is valid
21: Reserved
22: Running time reached
23: MODBUS communication virtual terminal
output
24: PROFIBUS/CANopen/DeviceNet
communication virtual terminal output
25: Ethernet communication virtual terminal output
26: DC bus voltage established
27: Z pulse output
28: Superposing pulses
29: STO action
30: Positioning completed
31: Spindle zeroing completed
32: Spindle scale division completed
33: In speed limit
34: EtherCAT/PROFINET communication virtual
terminal output
35: Reserved
36: Speed/position control switchover completed
37: Any frequency reached
38±40: Reserved
41: C_Y1 from PLC (Set P27.00 to 1.)
42: C_Y2 from PLC (Set P27.00 to 1.)
43: C_HDO from PLC (Set P27.00 to 1.)
