INVT GD270-090-4 - P12 group-Parameters of motor 2

Goodrive270 series VFD for fan and pump Function parameter list
-200-
Function
code
Name Description Default
Modify
with pre-alarm
0: Run at the present running frequency
1: Run at the frequency set through keypad
2: Run at the upper limit frequency
3: Run at the lower limit frequency
4: Run at the backup frequency upon exceptions
P11.52
Backup frequency
upon exceptions
0.00 Hz
±P00.03(Max. output frequency) 0 ƻ
P12 group²Parameters of motor 2
Function
code
Name Description Default
Modify
P12.00 Type of motor 2
0: Asynchronous motor (AM)
1: Synchronous motor (SM)
0 Ƽ
P12.01
Rated power of AM 2
0.1
±3000.0kW
Model
depended
Ƽ
P12.02
Rated frequency of
AM 2
0.01Hz
±P00.03(Max. output frequency) 50.00Hz Ƽ
P12.03
Rated speed of AM 2
1±60000rpm
Model
depended
Ƽ
P12.04
Rated voltage
of AM
2
0
±1200V Ƽ
P12.05
Rated current of AM
2
0.8
±6000.0A Ƽ
P12.06
Stator resistance of
AM 2
0.001
±ȍ ƻ
P12.07
Rotor resistance of
AM 2
0.001
±ȍ ƻ
P12.08
Leakage inductance
of AM 2
0.1
±6553.5mH ƻ
P12.09
Mutual inductance of
AM 2
0.1
±6553.5mH ƻ
P12.10
No-load current of
AM 2
0.1
±6553.5A ƻ
P12.11
Magnetic saturation
coefficient 1 of iron
core of AM 2
0.0
±100.0% 80% ƻ
P12.12
Magnetic saturation
coefficient 2 of iron
core of AM 2
0.0
±100.0% 68% ƻ
